Tekniske spesifikasjoner

Hjelm Waage LFBX

Length over all: 22,85 meter
Width: 6,0 meter
Brt: 90 Tonn

Displacement: 135 Tonn
Maximum Draft: 3,20M

Class: Sjøfartsdirektoratet + 1A1-N – ICE C Tug / Rescue
B P = 12 -14 Tonn
Fuel Capacity: 20 Tonns – Range 1800 NM
Fresh Water: 6,5 Tonn

Navigational equipment:

Radar JRC/JMA 5300 Mk2
Radar Koden
Furuno GPS GP 170
Olex Chartdisplay with 3D and dept data
Tiki Navionics Chartdisplay
AP 45 Autopilot
SAR Finder 121,5 MHZ
GPS Compass JRC

Communication equipment:

Furuno VHF FM 8900 S
1 x Sailor VHF
Furuno MF/HF FS 2575 C
Navtex
AIS

Tug and Rescue Equipment:

15 Tonn Towing Hook
1 Portable Salvage Pump
2 x DSB 16 prs Life Raft
12 stk. Survival Suit

Ship Technical Equipment Engine and propulsion:

Main Engine 2 x Scania DSI 14-57  560 HK
Twin Screw Hydraulikk Pitch
Bow Thruster  120 HK
Dubble Rudder
Ships Electrical 220 V  = 2 x Mitsubishi  aux 21 – 49 KW
2 generators 21 Kwh – 49 Kwh
Sentral Heater – Type Pyro
